Washburn - Two Storey - Narrow Lot (E1104-10)


This Narrow Lot Plan can be combined for duplex, triplex and fourplex combinations, or built by itself on a super narrow city lot. Talk to us about multi-plex units.


Standard
Plan

House Plan E1104-10 Exterior 3D View House Plan E1104-10 Main Floor Plan House Plan E1104-10 Upper Floor Plan House Plan E1104-10 Lower Floor Plan House Plan E1104-10 Rear 3D View House Plan E1104-10 Interior Kitchen 3D Area

Click thumbnails to see larger image below


House Plan E1104-10 Exterior 3D View
Plan in
Reverse

House Plan E1104-10 Exterior 3D View REVERSE House Plan E1104-10 Main Floor Plan REVERSE House Plan E1104-10 Upper Floor Plan REVERSE House Plan E1104-10 Lower Floor Plan REVERSE House Plan E1104-10 Rear 3D View REVERSE



ORDER THIS HOUSE PLAN

Floor Plan Details

  • Total Bedrooms:
  • 3
  • Bathrooms:
  • 3
  • Half Bathrooms:
  • 1
  • Main Floor Sq Ft:
  • 607
  • Upper Floor Sq Ft:
  • 619
  • Basement Sq Ft:
  • 333
  • House Width (Ft):
  • 22
  • House Depth (Ft):
  • 55

Room Details

  • Great Room:
  • 11'-11 x 12'-2 Main
  • Kitchen:
  • 10'-7 x 8'-10 Main
  • Dining Room:
  • 7'-11 x 10'-2 Main
  • Family Room:
  • 19'-4 X 11'-8 Basement
  • Laundry:
  • 6'-8 x 9'-8 Basement
  • Utility / Storage Room:
  • 12'-8 X 5'-0 Basement
  • Master Bedroom:
  • 13'-0 x 11'-2 Upper
  • Bedroom 2:
  • 10'-0 x 9'-10 Upper
  • Bedroom 3:
  • 9'-10 x 9'-0 Upper
  • All Bedrooms Have A Bathroom:
  • No
  • Master Bathroom:
  • 6'-10 x 5'-10 Upper
  • Bathroom 2:
  • 6'-11 x 7'-8 Upper
  • Bathroom 3:
  • 6'-5 x 6'-10 Basement

Kitchen Options

  • Eating Bar:
  • Yes
  • Open Plan:
  • Yes
  • Peninsula:
  • Yes

Living Style Options

  • Great Room Concept / Open Plan:
  • Yes

Interior Details

  • Great Living Room Fireplace:
  • Yes
  • Steam Room:
  • No
  • Skylight(s):
  • No
  • Hot Tub:
  • No
  • Sauna:
  • No

Master Bedroom Options

  • Pieces In Ensuite:
  • 3
  • Walk-In Closet:
  • 1

Garage Options

  • Garage Size:
  • 12'-2 x 20'-0
  • Number of Vehicles:
  • 1
  • Front Load:
  • Yes

Ceiling Options

  • Main Floor Ceiling Height:
  • 9
  • Upper Floor Ceiling Height:
  • 8
  • Basement Ceiling Height:
  • 9

Lot Details

  • Flat Lot (Less Than 36" Slope):
  • Yes

Construction Details

  • Framing Lumber:
  • 2x6
  • Roof:
  • Asphalt
  • Foundation:
  • In ground basement
  • Wall Finish:
  • Siding
  • Wall Finish:
  • Stone

Plan Permit Info

Plan Costs

  • Planbook 5 Print Sets 24x36 - ¼" Scale Copies:
  • $829.00

  • Planbook 8 Print Sets 24x36 - ¼" Scale Copies:
  • $928.00

  • Planbook purchase with PDF's:
  • $1,178.00
  • Extra 24x36 ¼" Scale Copies:
  • $33.00
  • Reverse Plan:
  • $249.00
  • Colour Rendering:
  • $69.00
  • 11" x 17" - 1/8" Scale Copy:
  • $18.00
  • Shipping within B.C.
  • $29.95
  • Shipping within Canada:
  • $50.00
  • Shipping to USA:
  • Please Ask For Quote
  • Shipping outside of North America:
  • Please Ask For Quote
  • Shipping Mounted Renderings:
  • Please Ask For Quote
