Legacy - Grade Level Entry House Plans (E1009-10)


Great Room Design with gas fireplace and feature stairs in living area, 3 bedrooms up plus room for a 2 bedroom suite in the Lower Level.


Standard
Plan

House Plan E1009-10 Exterior 3D View House Plan E1009-10 Main Floor Plan House Plan E1009-10 Lower Floor Plan House Plan E1009-10 Rear 3D View House Plan E1009-10 Interior Kitchen 3D Area

Click thumbnails to see larger image below


House Plan E1009-10 Exterior 3D View
Plan in
Reverse

House Plan E1009-10 Exterior 3D View REVERSE House Plan E1009-10 Main Floor Plan REVERSE House Plan E1009-10 Lower Floor Plan REVERSE House Plan E1009-10 Rear 3D View REVERSE



ORDER THIS HOUSE PLAN   RELATED HOUSE PLANS

Floor Plan Details

  • Total Bedrooms:
  • 5
  • Bathrooms:
  • 4
  • Main Floor Sq Ft:
  • 1497
  • Basement Sq Ft:
  • 1167
  • House Width (Ft):
  • 46
  • House Depth (Ft):
  • 47

Room Details

  • Great Room:
  • 14'-2 x 19'-2 Main
  • Kitchen:
  • 11'-7 x 11'-8 Main
  • Dining Room:
  • 9'-8 x 10'-0 Main
  • Den / Flex Room:
  • 10'-0 x 10'-0 Basement
  • Laundry:
  • 7'-0 X 6'-8 Main
  • Utility / Storage Room:
  • 10'-0 x 4'-8 Basement
  • Deck / Patio 1:
  • 23'-4 X 5'-8
  • Deck / Patio 2:
  • 11'-8 x 11'-2 Main
  • In-law Suite:
  • 800 Basement
  • Master Bedroom:
  • 14'-4 X 13'-0 Main
  • Bedroom 2:
  • 10'-0 X 10'-9 Main
  • Bedroom 3:
  • 10'-0 X 10'-9 Main
  • Bedroom 4:
  • 10'-10 X 12'-2 Basement
  • Bedroom 5:
  • 10'-0 X 10'-8 Basement
  • All Bedrooms Have A Bathroom:
  • No
  • Master Bathroom:
  • 8'-6 X 9'-7 Main
  • Bathroom 2:
  • 5'-0 X 8'-3 Main
  • Bathroom 3:
  • 10'-0 x 5'-0 Basement
  • Bathroom 4:
  • 9'-6 x 5'-0 Basement

Kitchen Options

  • Kithen Island:
  • Yes
  • Eating Bar:
  • Yes
  • Access To Deck:
  • Yes
  • Pantry:
  • Yes
  • Open Plan:
  • Yes

Living Style Options

  • Great Room Concept / Open Plan:
  • Yes

Interior Details

  • Great Living Room Fireplace:
  • Yes
  • Steam Room:
  • No
  • Skylight(s):
  • No
  • Hot Tub:
  • No
  • Sauna:
  • No

Master Bedroom Options

  • Pieces In Ensuite:
  • 4
  • Walk-In Closet:
  • 1

Garage Options

  • Garage Size:
  • 21'-0 X 23'-0
  • Number of Vehicles:
  • 2
  • Front Load:
  • Yes

Ceiling Options

  • Main Floor Ceiling Height:
  • 8
  • Basement Ceiling Height:
  • 9
  • Ceiling Comments:
  • Vaulted Ceiling in Great Room. 8'-0 Ceilings Up, 9'-0 Ceilings Down

Lot Details

  • Flat Lot (Less Than 36" Slope):
  • Yes
  • View To Street Side:
  • Yes

Construction Details

  • Framing Lumber:
  • 2x6
  • Roof:
  • Asphalt
  • Foundation:
  • Slab on grade
  • Wall Finish:
  • Stucco
  • Wall Finish:
  • Stone

Suite Options

  • Suites:
  • 1
  • Kitchen:
  • Yes
  • Dining Room:
  • Yes
  • Living Room:
  • Yes
  • 2 Bedroom:
  • Yes
  • Ensuite:
  • Yes
  • Laundry Facilities:
  • Yes
  • Garage Entrance:
  • Yes
  • Separate Exterior Entry:
  • Yes
  • Exterior Patio:
  • Yes

Plan Permit Info

Plan Costs

  • Planbook 5 Print Sets 24x36 - ¼" Scale Copies:
  • $969.00

  • Planbook 8 Print Sets 24x36 - ¼" Scale Copies:
  • $1,089.00

  • Planbook purchase with PDF's:
  • $1,389.00
  • Extra 24x36 ¼" Scale Copies:
  • $40.00
  • Reverse Plan:
  • $299.00
  • Colour Rendering:
  • $79.00
  • 11" x 17" - 1/8" Scale Copy:
  • $20.00
  • Shipping within B.C.
  • $29.95
  • Shipping within Canada:
  • $50.00
  • Shipping to USA:
  • Please Ask For Quote
  • Shipping outside of North America:
  • Please Ask For Quote
  • Shipping Mounted Renderings:
  • Please Ask For Quote
