Graham III (E1162-12)





Standard
Plan

House Plan E1162-12 Front 3D View House Plan E1162-12 Main Floor Plan House Plan E1162-12 Lower Floor Plan House Plan E1162-12 Rear 3D View

Click thumbnails to see larger image below


House Plan E1162-12 Front 3D View
Plan in
Reverse

House Plan E1162-12 Front 3D View REVERSE House Plan E1162-12 Main Floor Plan REVERSE House Plan E1162-12  Lower Floor Plan REVERSE House Plan E1162-12 Rear 3D View REVERSE



ORDER THIS HOUSE PLAN   RELATED HOUSE PLANS

Floor Plan Details

  • Total Bedrooms:
  • 3
  • # of Bedrooms on Main Floor:
  • 2
  • Bathrooms:
  • 2
  • Half Bathrooms:
  • 1
  • Main Floor Sq Ft:
  • 1060
  • Basement Sq Ft:
  • 478
  • House Width (Ft):
  • 38
  • House Depth (Ft):
  • 30

Room Details

  • Great Room:
  • 17'-6 X 10'-4 Main
  • Kitchen:
  • 13'-6 X 9'-0
  • Dining Room:
  • 13'-10 X 9'-3 Main
  • Family Room:
  • 13'-10 X 16'-10 Basement
  • Laundry:
  • 5'-0 X 5'-8 Main
  • Utility / Storage Room:
  • 4'-10 X 4'-4
  • Deck / Patio 1:
  • 14'-0 X 12'-0
  • Master Bedroom:
  • 13'-4 X 12'-6 Main
  • Bedroom 2:
  • 10'-0 X 9'-4 Main
  • Bedroom 3:
  • 10'-0 X 11'-2 Basement
  • All Bedrooms Have A Bathroom:
  • No
  • Master Bathroom:
  • 5'-6 X 6'-6 Main
  • Bathroom 2:
  • 5'-0 X 8'-0 Main

Kitchen Options

  • Kithen Island:
  • Yes
  • Walk Through Pantry:
  • Yes
  • Access To Deck:
  • Yes
  • Pantry:
  • Yes
  • Open Plan:
  • Yes

Living Style Options

  • Great Room Concept / Open Plan:
  • Yes

Interior Details

  • Great Living Room Fireplace:
  • Yes
  • Steam Room:
  • No
  • Skylight(s):
  • No
  • Hot Tub:
  • No
  • Sauna:
  • No

Master Bedroom Options

  • Pieces In Ensuite:
  • 3
  • Walk-In Closet:
  • 1

Garage Options

  • Garage Size:
  • 18'-10 X 23'-10
  • Number of Vehicles:
  • 2
  • Front Load:
  • Yes

Ceiling Options

  • Main Floor Ceiling Height:
  • 9
  • Basement Ceiling Height:
  • 9

Lot Details

  • Lot Sloping Upwards From Street:
  • Yes

Construction Details

  • Framing Lumber:
  • 2x6
  • Roof:
  • Asphalt
  • Foundation:
  • In ground basement
  • Wall Finish:
  • Siding
  • Wall Finish:
  • Stone

Plan Permit Info

Plan Costs

  • Planbook 5 Print Sets 24x36 - ¼" Scale Copies:
  • $969.00

  • Planbook 8 Print Sets 24x36 - ¼" Scale Copies:
  • $1,089.00

  • Planbook purchase with PDF's:
  • $1,389.00
  • Extra 24x36 ¼" Scale Copies:
  • $40.00
  • Reverse Plan:
  • $299.00
  • Colour Rendering:
  • $79.00
  • 11" x 17" - 1/8" Scale Copy:
  • $20.00
  • Shipping within B.C.
  • $29.95
  • Shipping within Canada:
  • $50.00
  • Shipping to USA:
  • Please Ask For Quote
  • Shipping outside of North America:
  • Please Ask For Quote
  • Shipping Mounted Renderings:
  • Please Ask For Quote
